Overview
IEC (International Electrotechnical Commission) standards represent the global benchmark for electrical and electronic product safety and performance. Our solar lighting products comply with key IEC standards covering photovoltaic modules, battery systems, and LED lighting — ensuring worldwide market acceptance and verified quality.
Key IEC Standards
| Standard | Title | Scope |
|---|---|---|
| IEC 61215 | Crystalline silicon PV modules — Qualification | Design qualification and type approval for solar panels |
| IEC 61646 | Thin-film PV modules — Qualification | Design qualification for thin-film panels |
| IEC 61730 | PV module safety qualification | Electrical, mechanical, and fire safety |
| IEC 62619 | Secondary cells — Safety requirements | Li-ion battery safety for industrial applications |
| IEC 60598-1 | Luminaires — Safety | General safety requirements for lighting fixtures |
| IEC 62471 | Photobiological safety | Blue light and UV hazard assessment |
| IEC 62133 | Secondary cells — Portable applications | Safety of sealed secondary cells |
IEC 61215 Test Sequence (Solar Panel Qualification)
- Visual Inspection: No visible defects (cracks, bubbles, delamination)
- Max Power Determination: STC measurement (1000W/m², 25°C, AM1.5)
- Insulation Test: 1000V DC + 2× system voltage, >40MΩ
- Wet Leakage Current: >40MΩ under water spray
- Thermal Cycling: -40°C to +85°C, 200 cycles
- Humidity-Freeze: +85°C/85% RH → -40°C, 10 cycles
- Damp Heat: +85°C/85% RH, 1000 hours
- UV Preconditioning: 15 kWh/m² UV exposure
- Mechanical Load: 2400 Pa front + 2400 Pa back
- Hail Impact: 25mm ice ball at 23 m/s
Pass Criteria
- Max power degradation <5% after each test sequence
- No visible defects (IEC 61215 Clause 10.1)
- Insulation resistance remains above requirements
- No ground fault or arc flash incidents
Certification Bodies
- TUV Rheinland (Germany)
- SGS (Switzerland)
- Intertek ETL (USA/UK)
- DEKRA (Netherlands)
- CSA (Canada)
